How To Operate your Construction with Formwork Planels?

1.When the hollow building template is used on the intersecting surface , it can be 14 mm thick, when used for transverse shear wall it should be 14 ~ 15 mm thick.

2. The distance between wood: (1) on the surface of the intersection wood square distance according to the thickness of the slab concrete, in general, if the thickness of slab concrete is less than 0.15 m ,the wood square distance  should be 250 ~ 300 mm.(2) the distance between wood of  the shear wall is adjusted by the height and thickness of the wall, for example, the wall is 2800 mm high and  300 mm thick, wood square distance should be 100 ~ 200 mm using a 14 mm thickness template, and be 150 ~ 250 mm with 15 mm thick planks of wood, if the shear wall, width of the pillar is thick more than 1 m, must add the fixed frame.

3. Between formwork panels is normally should no space, but if the temperature difference is 5 ~ 10 ℃, then should reserve 1 ~ 2 mm gap.

4. There shouldn't be gaps between the die shear wall and column puzzle, there must be wood square in internal Angle (the bottom of the wall) beam to insure the beam frame, wall and templates connect well. Shear wall formwork panels must be assembled into the whole piece before lifting, and then spread tablet, thus can reduce labor intensity, as well as improve the forming effect .

5. When nailing the formwork panels, the distance between the template edge and nail should be 15 ~ 30 mm, the strength of driving nail should be moderate, length of nails should be 30 ~ 35 mm, not too long or too short.

6.There must be a seam allowance for the wood in the beam bottom,make the wallboard stand on seam allowance of wood square, thus can ensure the leak leak not slurry and save wallboard material efficiently.

Testing Report

The testing is done under the following parameters:

1. Capability of material to last up to 60 times usage.

2. Flexibility and strength of materials

3. Heat resistance

4. deformation

5. water and moisture resistance

6. pull off capacity

If you have any questions or interest in our product, please call me at

8613453145207. You can also email to Beizhu05@beizhugroup.com.

Comparison of Metal and Plastic Formwork Panels

In the large construction market we can see many kinds of formwork panels. They are made by different materials, such as metal, hollow plastic, common plastic, steel, bamboo, playwood and so on.

Today i will show the difference between our Beizhu Hollow plastic formwork panels with metal formwork panel. See as follows:

1.The price of metal formwork is much higher than plastic formwork panels.

2.Because of the heavy weight of the metal formwork panels, the builder need to rent cranes and other equipment. The rent fee is also a big cost.

3.Because of the heavy weight of the metal formwork panels, the labor cost is higher, the speed of installation and speed of demoulding is slow.

4.The metal formwork panels must be used in High - rise building, in order to reduce the use of costs. If the floor number of the building is less than 30,we do not suggest to choose metal formwork panels.

5.Because of the re-usability, if use PP hollow plastic formwork to construct 30-storey high-rise, just need to purchase formwork panels for 3 storeys.

6.When use aluminum alloy formwork panels, the structural drawings and construction drawings must be very accurate, and need to design the size of formwork panels in advance, otherwise the size of formwork panels can not suitable for the project.

7.When using aluminum formwork ,size can not be modified, but plastic formwork can be cut according to the requirements.

8. One-time investment of metal formwork is high, very expensive.

9.After using, the surface of concrete and aluminum had a chemical reaction, the concrete surface is smooth, but there will be some small bubbles.

10. Because there is no corrosion resistance, so the aluminum formwork panels cannot be used on construction basement.

For more information about retro cast iron radiator, please call me at:+ 86134 5314 5207.You can also email your request to Beizhu05@beizhugroup.com.

What is Formwork Panel?

Formwork Panel is a die or a mould which used to shape and support the concrete until it attains sufficient strength to carry its own weight, including all supporting structures. It should be capable of carrying all imposed dead and live loads apart from its own weight.

Introduction to formwork panel

 Since the beginning of concrete construction formwork panel has been in use.

 There are nay new materials such as plastics, steel, and fiberglass are used in formwork panel.

 Man has pay greater attention to the erection, fabrication, design, and dismantling of formwork panel.

Defenition:

 1. As a structure

 2. Form it into the required shape and dimensions.

 3. Temporary which is designed to contain fresh fluid concrete.

 4. Support it until it cures sufficiently to become self supporting.

The term ‘formwork panel’ includes the actual material contact with the concrete, known as form face, and all the necessary associated supporting structure.

For more information about retro cast iron radiator, please call me at:+ 86134 5314 5207.You can also email your request to Beizhu05@beizhugroup.com.

Why our Formwork Panel has such Big Market? (2)

Beizhu group is the most advanced plastic formwork panel manufacturer in China.We developed and manufactured plastic formwork since 2008.

The new material formwork panel has many advantages:

To be continue.

7. Waste products can be recycled and reprocessed, making full use of waste materials, This property can greatly reduce the project cost, compared with wooden formworks  and bamboo formworks.

8. Environmental protection and energy saving, no pollution. Without any poisonous or harmful gas.

9.Demoulding easily. No need brushing release agent, only tapping, the formwork panels will fall off. Shorten working hours and speed up the construction schedule efficiently.

10. Easy to process. Sawing, drilling and nailing are all available. Formwork panels can be combined vertically and horizontally optionally

11. Easy to remove. Removing is convenient, quick and safe, and the supporting is also easy to operate, advantageous to the organization construction, effectively improving the construction schedule. Save cost up to 50%.

For more information about formwork panels, please call me at:+ 86134 5314 5207.You can also email your request to Beizhu05@beizhugroup.com.

Why our Formwork Panel has such a Big Market? (1)

Beizhu group is the most advanced plastic formwork panel manufacturer in China.We developed and manufactured plastic formwork since 2008.

The new material formwork panel has many advantages:

1.Light weight, high strength, high hardness, impact resistance, wear resistance.

2. Surface is smooth, bright and clean; Casting molding effect is good.

3.No absorption of moisture, no deformation, no mildew; Long-term immersion stratification in the water, no bubbles, sheet size stability, especially suitable for underground and damp environment.

4. Good toughness. Can be used to make other different shapes and size formwork panels.

5. Acid and alkali resistance, corrosion resistance; Very suitable for the engineering application in coastal areas, mine, as well as seawall. It is need not do any preservative treatment both in using and storing the formwork panels, which do not pollute the concrete surface.

6. The times of reuse can reach more than 60 times,even80-100 times， long service life.

For more information about our formwok panels, please call me at:+ 86134 5314 5207.You can also email your request to Beizhu05@beizhugroup.com.
